Gear Operated Double Offset Butterfly Valve
Products Details : Shenyang EO Valve Co.,Ltd is a leading China gear operated double offset butterfly valve manufacturer and supplier, and as a professional company, we have productive factory to offer you good price and service. GEAR OPERATED DOUBLE OFFSET BUTTERFLY VALVE DOUBLE OFFSET......
Products Details :
Shenyang EO Valve Co.,Ltd is a leading China gear operated double offset butterfly valve manufacturer and supplier, and as a professional company, we have productive factory to offer you good price and service. GEAR OPERATED DOUBLE OFFSET BUTTERFLY VALVE DOUBLE OFFSET...
Products Description :
Shenyang EO Valve Co.,Ltd is a leading China gear operated double offset butterfly valve manufacturer and supplier, and as a professional company, we have productive factory to offer you good price and service.
GEAR OPERATED DOUBLE OFFSET BUTTERFLY VALVE
DOUBLE OFFSET BUTTERFLY VALVE
Product Specifications :
DOUBLE OFFSET BUTTERFLY VALVE SIZES
Connection dimension | ||||||||||
Class 150 | Class 300 | |||||||||
Size | Length | D | D1 | D2 | Z-d | Length | D | D1 | D2 | Z-d |
Inch | mm | |||||||||
2” | 108 | 152 | 120.5 | 92 | 4-19 | 108 | 165 | 127 | 92 | 8-19 |
3” | 114 | 190 | 152.5 | 1278 | 4-19 | 114 | 210 | 168 | 127 | 8-22 |
4” | 127 | 229 | 190.5 | 157 | 8-19 | 127 | 254 | 200 | 157 | 8-22 |
5” | 140 | 254 | 216 | 186 | 8-22 | 140 | 279 | 235 | 186 | 8-22 |
6” | 140 | 279 | 241.5 | 216 | 8-22 | 140 | 318 | 270 | 216 | 12-22 |
8” | 150 | 343 | 298.5 | 270 | 8-22 | 150 | 381 | 330 | 270 | 12-26 |
10” | 160 | 406 | 362 | 324 | 12-25 | 160 | 445 | 387 | 324 | 16-29 |
12” | 178 | 483 | 432 | 381 | 12-25 | 178 | 521 | 451 | 381 | 16-32 |
14” | 190 | 533 | 476 | 413 | 12-29 | 190 | 584 | 514 | 413 | 20-32 |
16” | 216 | 597 | 540 | 470 | 16-29 | 216 | 648 | 571 | 470 | 20-35 |
18” | 222 | 635 | 578 | 533 | 16-32 | 222 | 711 | 628 | 533 | 24-35 |
20” | 229 | 699 | 635 | 584 | 20-32 | 229 | 775 | 688 | 584 | 24-35 |
24” | 267 | 813 | 750 | 692 | 20-35 | 267 | 914 | 813 | 692 | 24-41 |
30” | 292 | 887.5 | 846 | 813 | 44-22.4 | 292 | 990.5 | 921 | 845 | 36-38 |
32” | 318 | 941.5 | 900 | 864 | 48-22.4 | 318 | 1054 | 978 | 902 | 32-41 |
36” | 330 | 1057 | 1010 | 972 | 44-25.4 | 330 | 1172 | 1089 | 1010 | 32-45 |
≥36”, please inquiry. | ||||||||||
FEATURE :
1. Good performance of sealing in both directions, small torque.
2. Flow curve tending to straight line, excellent regulation performance for the butterfly valve.
3. Flange connection for convenient installation, suitable for vertical and horizontal type.
4. Variety of sealing materials.
5. The valve can be used as air release valve at pipe end, reliable performance.
6. The integration of seat ring and body brings long service life.
PACKAGING & DELIVERY
Packaging details : electric actuated butterfly valve: the strong plywood cases or as per the customer's request.
Delivery details : 4-5 weeks after receipt of down payment by T/T
Payment ： T/T, L/C, Western Union and PayPal
