1000 WOG Stainless Steel 2 Piece Threaded Ball Valve

Products Details :

Shenyang EO Valve Co.,Ltd is a leading China 1000wog stainless steel 2 piece threaded ball valve manufacturer and supplier, and as a professional company, we have productive factory to offer you good price and service. 1000 WOG STAINLESS STEEL TWO PIECE THREADED BALL VALVE...

Products Description :

Shenyang EO Valve Co.,Ltd is a leading China 1000wog stainless steel 2 piece threaded ball valve manufacturer and supplier, and as a professional company, we have productive factory to offer you good price and service.

1000 WOG STAINLESS STEEL TWO PIECE THREADED BALL VALVE

Product Specifications :

800PSI~1000PSI

Features

1.Material: Random Polypropylene(Type 3)

2.Sizes: 16mm to160mm

3.Pressure Rating: 1.0Mpa,1.25MPa, 1.6MPa, 2.0MPa ,2.5MPa

4.Colors: light gray, white or other colors on request

5.Connection: socket fusion joint, electric fusion joint or transition joint

6.Standard: ISO15874 tested by Body cote, BS6920 tested by WRAS

7.Applications: Cold or hot water supply, heating system including flooring heating, wall heating andradiating system, Central air conditioning system, industrial liquids transportation

Advantages

1.High Temperature Resistance: the maximum sustained working temperature is up to 110Degrees Celsius,the maximum transient temperature is up to 95 Degrees Celsius

2.Heat Preservation: low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe

3.Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium

4.Corrosion Resistant: resist chemical matters or electron chemical corrosion

5.Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system

6.Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes

7.Long Life: more than 50 years under normal conditions

8.Recycled and Environment-friendly

Description

Material:

Stainless Steel: 1) SS316 / ASTM A351-CF8M / DIN1.4408

2) SS304 / ASTM A351-CF8 / DIN1,4401

3) SS202 / ISO A-3

4) SS201 / ISO A-2

Carbon Steel : S45C / ASTM A216GR-WCB / DIN1.0619

Thread: ASME B 1.20.1(NPT), BS 21(BSP), DIN 2999(PT)/259, ISO 228/1.

Size: 1/4", 3/8", 1/2", 3/4", 1", 11/4", 1.1/2", 2" ,2.1/2", 3", 4"

Design & Manufacture Std.: API608, ASME B16.34

Investment casting body & caps.

Bottom-loaded Blow-out proof stem

Bore: Reduce / Full bore

Working pressure: 1000PSI ( PN63 ) WOG

Locking Device available.

CE marking available.

Inspection Test: API 598.

Suitable media: water, oil, air and some corrosive liquids.

PACKAGING & DELIVERY

Packaging details : electric actuated butterfly valve: the strong plywood cases or as per the customer's request.

Delivery details  : 4-5 weeks after receipt of down payment by T/T

Payment ： T/T, L/C, Western Union and PayPal

FAQ :

1. What is your difference from other competitors?

1). Scale: 82,000.00 square meters non-dust workshop

2). Condition: good after sale service

3). Equipment: 350 sets advanced machining facilities, 5 automatic production lines

4). R&D: valve research and design center

2. How do you control your quality?

1). The foundry is built to promise our raw material better before production.

2). Strict QC system is set up for the superior quality guarantee.
