Butt Weld Cast Steel Check Valve
Products Details : Shenyang EO Valve Co.,Ltd is a leading China butt weld cast steel check valve manufacturer and supplier, and as a professional company, we have productive factory to offer you good price and service. Cast steel Swing type butt weld end check Valve, Manufactured By... Products...
Products Details :
Shenyang EO Valve Co.,Ltd is a leading China butt weld cast steel check valve manufacturer and supplier, and as a professional company, we have productive factory to offer you good price and service. Cast steel Swing type butt weld end check Valve, Manufactured By...
Products Description :
Shenyang EO Valve Co.,Ltd is a leading China butt weld cast steel check valve manufacturer and supplier, and as a professional company, we have productive factory to offer you good price and service.
Cast Steel Swing Type Butt Weld End Check Valve, Manufactured By Professional Valve
Product Specifications :
1). Size: 1/2"-36"
2). Material:CF8, CF8M, CF3, CF3M. 304 ,304L,316,316L. WCB, WCC
3). Class: 150LB, 300LB, 600LB, 900LB,1500LB, 2500LB
4). Suitable medium: water, oil, air and some corrosive liquid
5). Temperature range: -20°C - 425°C
6). Operate: Hand wheel, pneumatic, electrical actuator
7). Design and manufacture: API 6D & API 600
8). Inspection and Test: API 6D & API 598
9). Flange end dimension: ASME B16.5 & MSS-SP-44
10). Butt-welding end dimension: ASME B16.25
11). Face to face: API 6D & ASME B16.10
12).Certificate: API, CE, TS
MAIN MATERIAL LIST:
NO. | Part Name | ASTM Specification | ||||
A 216 | A 352 | A 217 | A 351 | |||
|
| WCB | LCC | WC6 | C5 | CF8M |
1 | Body | A 216-WCB | A 352-LCC | A217-WC6 | A 217-C5 | A 351-CF8M |
2 | Seat Ring | A 105, LF2, 316, or 304 | ||||
Seat Ring Surface | 13Cr, HF (CoCr-A), 316, 304, or Monel | |||||
3 | Pin | 13Cr | 316 | |||
4 | Disc | 13Cr | 316 | |||
5 | Arm | A 216-WCB | A 351-CF8M | |||
6 | Nut | 304 | 316 | |||
7 | Bolt | 304 | 316 | |||
8 | Seal Ring | 304/Flexible Graphite | ||||
9 | Ring | 13Cr | A 276 Type 316 | |||
10 | Cover | A 216-WCB | A 352-LCC | A217-WC6 | A 217-C5 | A 351-CF8M |
11 | Cover Bolt Cover Nut | A 193-B7 | A 320-L7 | A 193-B7 | A 193-B8 | |
A 194-2H | A 194-7 | A 194-2H | A 194-8 | |||
NOTE:OTHER METERIALS ARE AVALIABLE UPON REQUEST
Our Advantage:
1). Scale: 82,000.00 square meters non-dust workshop.
2). The foundry is built to promise our raw material better before production.
3). Equipment: 350 sets advanced machining facilities, 5 automatic production lines
4). R&D: valve research and design center
5). Strict QC system is set up for the superior quality guarantee.
6). Competitive factory price can offer for customers
PACKAGING & DELIVERY
Packaging details : electric actuated butterfly valve: the strong plywood cases or as per the customer's request.
Delivery details : 4-5 weeks after receipt of down payment by T/T
Payment ： T/T, L/C, Western Union and PayPal
