High Quality Motorised Butterfly Valve Pneumatic Valve
High Quality Motorised Butterfly Valve Pneumatic Valve;Anti static, small fluid resistance, good sealing performance of the valve seat, and small friction loss with the ball , prolong the service life of the ball valve.
| Quick Details | |
| Standard or Nonstandard: | Standard |
| Structure: | Butterfly |
| Pressure: | Medium Pressure |
| Power: | Electric |
| Material: | Alloy, Aluminum alloy |
| Temperature of Media: | Medium Temperature |
| Media: | Water, Gas/Oil/Water/Base/Acid/Others |
| Port Size: | Standard |
| Place of Origin: | China (Mainland) |
| Model Number: | D2-05 |
| Brand Name: | EO |
| Application: | General, Valves for Solid/Liquid and Gas |
| Product Name: | motorised butterfly valve pneumatic valve |
| Color: | Blue |
| Type: | Micro Motor |
| Operating time: | 5s/10s/20s/30s |
| Function: | control ball valve, butterfly val |
| Reted Power: | 10w/20w |
| Certificate: | CE |
Application:
It is mainly used for cutting off or connecting medium in pipeline, and can also be used for fluid regulation and control.
Advantage:
Anti static, small fluid resistance, good sealing performance of the valve seat, and small friction loss with the ball , prolong the service life of the ball valve.
Our Service
Spot delivery, including delivering small batches of goods
Provide wide-range and complete materials series products
Cutting plates, including complex shapes of materials and special processing and disposal
Cutting bars and strips
Our application technology expert provide the best material and recommendation
One-stop service
